Description
Operating Voltage Operating Frequency Operating Power Operating Temperature Weight High Current (Overload) Range Asymmetry Waiting (t) Display Contact Protection Class Connection Type Cable Diameter Mounting Working Altitude 100-240V AC 50 / 60 Hz <10VA -20°C – 55°C <380Gr CON-12: 1A-12A CON-18: 1A-18A CON-25: 1A-25A %50 fixed (2sec fixed delay) 0.1sec – 10sec 2 LEDS + 3 Displays 2NO+2NC; 3A/250VAC IP20 Terminal Connection Control Max2.5mm² Power Max6mm² DIN Rail Mounting <2000 meter
