    ENERGY-01-DIN-100A Energy Meter

    ENERGY-01-DIN-100A Energy Meter

    ENERGY-01-DIN-100A Energy Meter

    The device monitors the total active energy (ΣkWh) of the three phases by metering AC RMS mains voltage and RMS mains current. Current and Voltage transformer primer value can be adjusted with the parameter menu.Our device is a cost effective solution and has all the essential parameters especially for automation firms working in the area of energy saving,mains analysing and product cost analysing.The device can be integrated to scade systems easily by using MODBUS-RTU with RS485 port.With the data table(register table), each three phases – neutral voltages,phase-phase voltages, currents and neutral current, frequency, power factors,power factor distorsion , import and export active power,reactive power, active and reactive energy, amplitude and % value of voltages and currents of the each odd harmonics from 3. to 31., and zero cross angles of three phases voltages and currents can be monitored and analysed.

    Categories: , Brand:

    Description

    Connection 3P&4W Active Power:P1,P2,P3 No Reactive Power:Q1,Q2,Q3 No PF1,PF2,PF3 No Imp-exp. Active Energy kWh 1 class Imp-ex Reactive Energy kVARh 2 class Demand ve Peak No Energy pulse output No RS485 – MODBUS RTU Ok Password protection Ok Ambient temperature -5 C….+50 C Storage temperature -20 C….+70 C Display LED Display Current Transformer Harici 100 A Current transformer ratio 1 Voltage transformer ratio 1….4000 Auxiliary supply voltage 230 Vac <4VA Dimensions 105x90x59 mm Quantity in 1 box 12

    Catalog PDF

    Download
