Description
Operating Voltage 150-260V AC Operating Frequency 50 / 60 Hz Operating Power <6VA Operating Temperature -20°C…..55°C Weight <210Gr Current Set. Range 0.5A – 5A AC Input (K-I) X/5A Current Transformer Start Time (Inrush) 1sec – 10sec Delay Time (Waiting) 0.5sec – 2.5sec Display 3 LEDS Contact 1NO+1NC 5A/250VAC Protection Class IP20 Connection Type Terminal Connection Cable Diameter Max2.5mm² Mounting DIN Rail Mounting Working Altitude <2000 meter
