Description
Rated Voltage : 220/230 Vac Operating Range : (0,8 – 1,1)x Un (Un nominal voltage) Frequency : 50 Hz. Pressure switch output : Out 1.pressure switch input : P1 2.pressure switch input : P2 3.pressure switch input : P3 Pump contact outputs : H1,H2,H3 Contact Current : Max.3 Amp/240Vac Power Consumption : < 5VA Device Protection Class : IP20 Terminal Protection Class : IP00 Ambient Temperature : -5 C….+50 C Humidity : %15….%95 (without condensation) Connection Type : Vertical mounting on box or on rail Dimensions : 112x75x50 mm
