Description
Operating Voltage Operating Frequency Operating Power Operating Temperature Input Voltage (L-N) Voltage Measuring Range Input Current Current Measuring Range Voltage, Current, Accuracy Active Energy Accuracy Reactive Energy Accuracy Supported Connection Current Transformer Ratio Voltage Transformer Ratio Harmonic Voltage Harmonic Current Communication Contact input Digital Input Weight Protection Class Panel Hole Measurement Connection Type Cable Diameter 85V – 240 AC 50 / 60 Hz <10VA -20°C…..55°C 5V – 330V AC 5V – 330kV 1mA – 5,5A 1mA – 50.000A %±0.5 %±1 %±2 3P3W 1….1000 1,0….9999 3 – 31 3 – 31 RS485 Modbus RTU Baudrate: 1200bps-38400bps Stop Bit: 1 or 2; Parity: None, Even, Odd 3A / 250V AC [Resistive Load] 9V – 24V DC <300Gr IP54[Front Panel], IP00[Body] 91mm x 91mm Plug-in Terminal Connection 1.5mm²
