Description
3 phase 3P&4W Connection Ok 1 phase 1P&2W connection No Voltage Ok Current(A) Ok Frequency Ok True RMS Ok Phase sequnce control Ok Phase failure Ok Over Voltage Protection 390-460 V Under Voltage Protection 300-370 V Voltage Unbalance Protection %5-%20 Over Current Protection Ok Under Current Protection Ok Current unbalance protection %5-%40 Over/Under Frequency protection 40-70 Hz Error locking (LATCH) function Ok Current transformer ratio No 2-100A Ok Relay output 1 adet Ambient temperature -5 C….+50 C Storage temperature -20 C….+70 C Supply voltage 230 Vac<3VA Dimensions 72x72x80mm Quantity in 1 box 12
